JORDAIR VERTICAL AIR-KAT SERIES COMPRESSORS

JORDAIR VERTICAL AIR-KAT SERIES COMPRESSORS



Product Code: JOR-VERTICALAIR-KATCOMPRESSORS
CALL FOR PRICING

Description Technical Specs Extended Information

All AIR-KAT compressors are PLC controlled and can run in either manual or automatic start modes, and include oil, interstage and discharge pressure gauges as well as an hour meter and "Power On" light. High air temperature and low oil pressure shut down alarms as well as interstage and final pressure relief valves protect the compressor and its components. Our compressors are designed to auto drain every 15 minutes into a silent collection system. Jordair's standard aluminum alloy filtration systems are all rated for 6500 PSIG* service and include an oil and water separator, check valve, purifier, pressure maintaining valve, manual drain valve and auto drain cycle counter. All Bauer blocks have a crankshaft rated for up to 30,000 operating hours.
Features
  • New high velocity, full flow cooling fan assembly that produces high velocity airflow over the coolers, pressure cylinders and crankcase to cool the compressed air and lubricating oil
  • Drive gear designed for an operating life of up to 30,000 hours
  • Stainless steel inter and after-coolers for high efficiency cooling and corrosion free operation
  • Cylinders are hardened through a plasma-nitrate process for up to 10,000 hours of operating life and low wear with excellent lubricating oil retention
  • Redesigned rings for the HP piston are synthetic material for low wear and a long operating life with very little oil carry over
  • Single-piece crankcase made of a high strength aluminum alloy for higher stability, larger oil capacity, and low vibration
  • Full flow oil system with a crankshaft-driven gear pump and full flow oil filter
  • Visual oil level indicator is designed show the accurate oil level
  • New reed valve on the first stage which offers higher efficiency and redesigned intake filter reduces intake valve noise
  • New final stage oil cooled cylinder and cylinder-head for lower air discharge temperature
